Electrical transport measurements
We have several (high-speed) measurement systems available to probe electrical transport of organic electronic devices, as well as their voltage and frequency dependent complex impedance. For transport measurements on organic field effect transistors, a Keithley 4200A-SCS Parameter Analyseris available, allowing voltages of up to ±200V on gate, source and drain terminals and impedance starting at 1 kHz. For optoelectronic device characterization, we have installed a Fluxim PAIOS (Platform for all-in-one Characterization of Solar Cells and (O)LEDs) system, which integrates high-speed transients, electro-optical and impedance measurements at voltages up to ±30V and transients with nanosecond resolution and impedance up to 10 MHz. For very low frequency impedance measurements, a dedicated Solartron 1260A impedance analyzer with dielectric interface allows measurements down to the mHz range, also with high voltage of up to ±40V; higher external voltages can be applied for specific measurements.
Most of the setups are mobile and can be connected to either a cryostat, allowing measurements in a temperature range of 70K up to 400K, or the Glovebox-System to measure samples without the need for a vacuum transfer. A thermoelectric cryostat is also available in the Glovebox-System.
![](https://assets.uni-augsburg.de/media/filer_public_thumbnails/filer_public/9c/b4/9cb4041c-0e41-428f-bebb-93374008a503/electricaltransportmeasurement.jpg__1080x2000_q85_subject_location-451%2C232_subsampling-2.jpg)
Contact person: Dr. Alexander Hofmann
